Electronic Lettering Machine:LM-550A/PC

เครื่องพิมพ์ปลอกสายไฟและฉลาก รุ่น LM-550A/PC MAX Letatwin
สำหรับการทำมาร์คกิ้งในระบบไฟฟ้า
“MAX”

ชุดเครื่องพร้อมหมึกสำหรับพิมพ์ กระเป๋ากันกระแทก สาย USB



Description

เครื่องพิมพ์ปลอกมาร์คสาย และ เทปพลาสติก สำหรับงานไฟฟ้า ตู้คอนโทรล และอุตสาหกรรมต่างๆ (Marking Tube & Label,Printing Machine)

Professional choice for your cable marking job!
⊗ Our fastest printing speed ever!                                         ⊗ Versatile printing capability! (Tube Ø 1.5-8.0mm.)
⊗ Connect ro your PC with a USB cable or a USB flash drive    ⊗ Comes with plastic carry case
⊗ The dedicated “LETATWIN PC EDITOR” application software included.

Is entirely new designed lettering for professional use of both tube and label marking with many attractive and user-friendly features.
Professional choice for your marking job! The class’s fastest marking job! High volume memory! USB makes PC access easier!

♥ Long consumable roll length
LM-550A/PC adopts the dedicated consumables which have a longer roll length. Long roll length saved reloading time.

♥ High-speed marking
LM-550A/PC has an enhanced feeding system that provides you with marking speed at 40mm/sec.
LM-550A/PC can make approx 52pcs of 20mm-length tube per minute.

♥ Maximum 250,000 characters built-in large memory storage

♥ Easy access from your PC with USB
    LM-550A/PC features a USB port for a direct cable connection with a Windows PC (for direct printing or file transfers)
and a USB flash drive slot for transferring computer files made in our dedicated “LETATWIN PC EDITOR” software.
  – PC Requirements for Windows 10/8.1/8/7 operating systems.Windows is a registered trademark of Microsoft
Corporation(US) in U.S.A or other countries.

♥ Versatile marking capability
    various marking media and sizes
– ø 1.5-8.0 mm. PVC tubes
– ø 2.0-6.5 mm. Heat Shrinkable tubes
– 5mm./9mm./12mm. wide MAX dedicated tapes
– I.D.plates
– Oval tubes (for the availability of European style marking media, please contact our distributor)
To optimize printing quality, multiple combinations of settings (such as vertical/horizontal print positions and print density)
can be saved to support European style marking media etc.

♥ Large and backlit LCD display
    Backlit LCD display makes your confirmation of input contents easy,even if you work in a dim job site.

♥ The pitch can be set up to maximum 60mm.
    – Marking on tape: 4 up to 60 mm.
– Marking on tube: 10 up to 60 mm.
(Auto pitch function is available for more than 60mm)

♥ Economical refill-type ink ribbon

♥ Specifications

Items Contents
Name MAX ELECTRONIC LETTERING MACHINE LM-550A/PC
Dimensions 295(W) x 293(D) x 94(H) mm
Wight 2.4kg
Printing method Thermal transfer method (300dpi)
Display LCD dot matrix: 64×160 Pixel (Backlit)
Printing speed 40mm/s (Standard) , 20mm/s (Low temperature mode)
Maximum Printing length Tube: 20m , Tape: 5m
By multiple copy printing,maximum 30copies, upto Tube;100m, Tape;7m
Maximum number of characters to input 5,000 characters per file
Characters size 1.3,2,3,4,6mm height
Usable tube ø1.5-8.0mm. (PVC tubes) (For ø1.5-2.0mm. tubes,the dedicated attachment (standard accessory) is required)
ø 2.0-6.5 mm. (Heat Shrinkable tubes)
Usable tape Width 5,9,12mm. (Max genuine tape)
Tube cutting method Auto half cut, manual full cut
Internal memory 250,000 characters (Maximum 50 files)
External memory USB memory
Interface USB 2.0 full speed
Power supply DC12V,3.0A (Use only specified AC adapter (100V-240V) included in the package
Power consumption MAX 30W
Operating environment 10°C to 35°C



CONSUMABLES

(ตลับใส่ผ้าหมึก)
INK RIBBON CASE
LM-RC500 10PCS/BOX



(ผ้าหมึกสำหรับพิมพ์)
ECONOMICAL INK RIBBON
LM-IR50B (BLACK) 110m/ROLL 10 ROLLS/BOX



ปลอกสายสำหรับพิมพ์

MAX HIGH QUALITY TUBE
LM-TU432L White 3.2mm. x 200m/Roll 1 Roll/Box (Recommended cable size 1.0mm2)
LM-TU436L White 3.6mm. x 200m/Roll 1 Roll/Box (Recommended cable size 1.5mm2)
LM-TU442L White 4.2mm. x 200m/Roll 1 Roll/Box (Recommended cable size 2.5mm2)
LM-TU452L White 5.2mm. x 135m/Roll 1 Roll/Box (Recommended cable size 6.0mm2)
LM-TU464L White 6.4mm. x 100m/Roll 1 Roll/Box (Recommended cable size 10.0mm2)
LM-TU480L White 8.0mm. x 70m/Roll 1 Roll/Box (Recommended cable size 16.0mm2)



 UBON QUALITY TUBE
UT-N2.5W White 2.5mm x 200m/Roll 1 Roll/Pack
(Recommended cable size 0.75mm2)
UT-N3.2W White 3.2mm x 200m/Roll 1 Roll/Pack
(Recommended cable size 1.0mm2)
UT-N3.6W White 3.6mm x 200m/Roll 1 Roll/Pack
(Recommended cable size 1.5mm2)
UT-N4.2W White 4.2mm x 200m/Roll 1 Roll/Pack
(Recommended cable size 2.5mm2)
UT-N5.2W White 5.2mm x 100m/Roll 1 Roll/Pack
(Recommended cable size 6.0mm2)
UT-N6.0W White 6.0mm x 100m/Roll 1 Roll/Pack
(Recommended cable size 10.0mm2)

เทปพลาสติกสำหรับพิมพ์

 TAPE CASSETTE
LM-TP505Y
(YELLOW) :
5mm.(W) X 8M. (L)/pc. 10PCS./BOX
LM-TP505W
(WHITE) :
5mm.(W) X 16M. (L)/pc. 10PCS./BOX
LM-TP509Y
(YELLOW) :
9mm.(W) X 8M. (L)/pc. 10PCS./BOX
LM-TP509W
(WHITE) :
9mm.(W) X 16M. (L)/pc. 10PCS./BOX
LM-TP309T
(TRANSPARENT) :
9mm.(W) X 8M. (L)/pc. 10PCS./BOX
LM-TP312Y
(YELLOW) :
12mm.(W) X 8M. (L)/pc.10PCS./BOX
LM-TP312W
(WHITE) :
12mm.(W) X 16M. (L)/pc.10PCS./BOX
